Zemic High Stable Piezoresistive Pressure Sensor with Silicon Oil Filled Technology

Looking for Zemic High Stable Piezoresistive Pressure Sensor with Silicon Oil Filled Technology? Find it at our factory. High-quality sensors for your needs.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
Overview

Basic Info.

Model NO.
B3G-C3-150
IP Rating
IP68
Certification
ISO
Customized
Yes
Transport Package
Carton
Specification
20*20*15cm
Trademark
ZEMIC
Origin
China(Mainland)
HS Code
9031809090
Production Capacity
100000PCS

Product Description

Product Description



ZKMD-6857D Pressure Sensor



The ZKMD-6857D pressure sensor is a high-performance device designed for various applications in medical electronics, automotive electronics, consumer electronics, sports and fitness equipment, Internet of Things, and more. Its compact size and easy installation make it a versatile choice for a wide range of industries.



Key Features:



  • DIP-like packaging form for convenient integration

  • Digital compensation for offset, sensitivity, temperature drift, and nonlinearity

  • Generates a calibrated signal using the power supply voltage as a reference

  • Standard digital signal after temperature compensation


  •


Applications:



  • Medical fields: electronic blood pressure monitors, ventilators, oxygen concentrators, and monitors

  • Consumer electronics: atomizers, sprays, negative pressure sensors, and more

  • Sports and fitness equipment: massagers, massage chairs, air cushion beds, and more

  • Other fields: water heaters, oxygen water machines, beer machines, coffee machines, air pumps, vacuum pumps, pressure instruments, and more


  •


Choose the ZKMD-6857D pressure sensor for reliable and accurate pressure measurements in your industry. Trust Anhui Zhongkemi dian Sensor Co., Ltd. for high-quality sensor solutions.

1.2Product features





Product Description




Anhui Zhongkemi dian Sensor Co., Ltd.



Product Description



The Measurement Range of this sensor is from -100kPa to 1000kPa, allowing for accurate pressure readings. It is a Gauge Pressure Type sensor, capable of measuring both positive and negative pressure.



The sensor operates on a Power Supply Voltage of 2.5V to 5.5V, ensuring compatibility with various devices. With a low Current Consumption of 5uA per measurement, it is energy-efficient.



In sleep state, the sensor has an ultra-low current consumption of less than 100nA at 25°C, preserving battery life. The 24-bit ADC provides high resolution for accurate measurements.



With a temperature accuracy of ± 0.5°C at 25°C, this sensor ensures precise temperature readings. It is suitable for measuring non-corrosive gases.



The sensor offers an I2C Signal Output and features wide temperature compensation, enhancing its versatility and compatibility with different systems.



Performance Index



Power Supply: 5±0.25V DC



reference temperature: 25ºC
project numerical value unit
Accuracy* ±2 %Span
response time 2.5ms@OSR_P=1024X Ms
SDA/SCL Pull-up resistor 4.7 Koh m
ESD HBM 4000 V
  5x   (FS≤40kPa) Rated

Overload pressure
  2 ×  (FS≥100kPa) Rated
  1.5 ×  (FS>200kPa) Rated
compensation temperature 0 ~60 ºC
operation temperature -30 ~100 ºC
Storage temperature -30 ~125 ºC

Product Description:





Introducing the Anhui Zhongkemi dian Sensor Co., Ltd. Pressure Sensor, designed to provide unparalleled accuracy and reliability in pressure measurements. With its advanced technology and precision engineering, this sensor is the perfect choice for a wide range of applications.





The accuracy of our pressure sensor is second to none. It effectively eliminates all types of errors, including linear, repetitive, and hysteresis errors, ensuring precise and reliable pressure readings. The accuracy level may vary depending on the pressure range, so we recommend consulting our customer service for more detailed information.





Whether you need to measure pressure in industrial processes, automotive applications, or scientific research, our pressure sensor is up to the task. Its exceptional accuracy guarantees precise data, allowing you to make informed decisions and optimize your operations.





Don't settle for subpar pressure sensors that compromise accuracy and reliability. Choose the Anhui Zhongkemi dian Sensor Co., Ltd. Pressure Sensor and experience the difference it can make in your measurements. Contact our customer service today for more information!

3.Electrical characteristics

parameter minimum value Typical value Maximum value unit notes
Supply Voltage 2.5   5.5 V
Standby current   100   nA
LDO output 1.62 1.8 1.98 V ' regulator_sel '= 0
  3.24 3.6 3.96 V ' regulator_sel '= 1
PSRR   60   dB
resolution ratio   24   Bits
Output data resolution 24 Bits LSB=(1/2^23)*VEXT
(' raw_data_on'=1)
Input common mode signal suppression ratio 80 110
Built in temperature sensor accuracy     ±0.5 ºC @25ºC
      ±1 ºC -40 to 85  ºC
Output data resolution 16 Bit LSB = (1/256)  ºC
clock frequency     400 khz I2C  communicate





Product Description: Range Example



Note: Before purchasing, please consult customer service at Anhui Zhongkemi dian Sensor Co., Ltd. to check the mass production status of the ordered model specifications, as a small number of model specifications have been discontinued.




Pressure range(kPa) model
 ~  2.5 ZKMD-6857D025HPG
0  ~  5 ZKMD-6857D005KPG
 ~  10 ZKMD-6857D010KPG
 ~  20 ZKMD-6857D020KPG
  40 ZKMD-6857D040KPG
 ~  100 ZKMD-6857D100KPG
 ~  200 ZKMD-6857D200KPG
 ~  700 ZKMD-6857D700KPG
 ~  1000 ZKMD-6857D001MPG
-100  ~  0 ZKMD-6857D100KPGN
-5  ~  5 ZKMD-6857D005KPGPN
-40  40 ZKMD-6857D040KPGPN
-100  ~  100 ZKMD-6857D100KPGPN
-100  ~  200 ZKMD-6857D200KPGPN
-100  ~  700 ZKMD-6857D700KPGPN
-100  ~  1000 ZKMD-6857D001MPGPN
Various ranges and parameters can be customized according to needs
